EJA115E Differential Pressure Transmitter with Built-in Orifice Plate
The EJA115E Differential Pressure Transmitter with Built-in Orifice Plate is suitable for micro-flow measurement and outputs a 4–20mA DC signal corresponding to the measured flow rate. It can measure, display, or remotely monitor static pressure, and features functions such as fast response, remote setting, and self-diagnosis.
Functional Characteristics of the EJA115E:
Square root output accuracy: ±0.055%
Stability: ±0.1% URL/10 years (URL = Upper Range Limit, referring to the upper limit of the measurement range)
TUV and Exida SIL 2/3 certifications
Response time: 90 ms ~ 150 ms
10-segment signal curve characterization
Local Parameter Setting (LPS)
Supports communication protocols including HART 5/7, low-power HART (1~5V DC), FF Fieldbus, PROFIBUS PA, and BRAIN.
