Rosemount 3144P temperature transmitter provides you with temperature measurement with industry-leading accuracy, stability and reliability. The transmitter has a double-cavity housing, which can ensure reliability and advanced diagnosis, and ensure the normal operation of your measuring point. This transmitter combines Rosemount X-well™ technology with Rosemount 0085 pipe clamp sensor, which can accurately measure the process temperature, eliminating the need for hot sleeve or process infiltration.
specifications
input
Support universal sensor input (RTD, T/C, mV, ohms), and support single sensor or double sensor assembly.
output signal
4-20 ma/hart protocol, FOUNDATION™ fieldbus protocol
shell
Double-cavity field installation
Display/interface
Large LCD with percentage range graphics and buttons/switches
diagnose
Basic diagnosis, Hot Backup™ function, sensor drift warning, thermocouple aging, min/max tracking.
Calibration option
Transmitter-sensor matching (Calende-Van Dussen constant), custom adjustment.
